Name: 24" Wide Refrigerator-Freezer
Brand: Summit
SKU: CT663BK
Availability: BackOrder

24" Wide Refrigerator-Freezer

Model : #CT663BK

24" Wide Refrigerator-Freezer

Model: CT663BK

+3more

24" Wide Refrigerator-Freezer

Model: CT663BK

Color : Black

Key Features

Dual evaporator
Slim counter height dimensions
Cycle defrost
Adjustable glass shelves
Door storage
Fruit and vegetable crisper
Wine shelf
Hidden evaporator

Description

Summit's Peak24 series of undercounter European-made refrigeration features energy efficient refrigerator-freezer choices that offer the largest capacity in the industry for recessed installation in 24" openings. Sized with a 24” footprint, the ENERGY STAR certified CT663BK refrigerator-freezer offers over 5 cu.ft. of storage capacity, a larger interior than many units in this size class. This model features a black exterior finish with a user-reversible door swing. A stainless steel handle completes the look. Inside, the CT663BK features a dual evaporator to allow separated cooling of the fresh and frozen food sections. The refrigerated compartment utilizes low maintenance automatic defrost, while the interior freezer compartment is manual defrost to achieve lower storage temperatures ideal for ice cream and other frozen food. The deluxe interior includes adjustable glass shelves for spill-proof storage and easier cleaning, as well as a scalloped wine shelf to hold wine and champagne bottles safely in place. Door racks offer additional convenience for tall bottles and condiments and a clear crisper drawer ensures your produce is stored under the ideal conditions. This model includes automatic interior lighting and an adjustable dial thermostat. This model is UL listed for residential use. With its large capacity and user-friendly features, this refrigerator-freezer is a convenient option for homes, offices, schools, and other settings in need of reliable cold storage. Additional choices are available in lower ADA height. Browse the full Summit catalog to discover the perfect appliance for your refrigeration needs.

Documents

USE & CARE

View | Download

PDF, 595.34 KB

Available from R W McDonald and Sons, serving customers throughout Pennsylvania.

Features

Specifications

Features

Dual evaporator

Our unique and efficient design separately cools the refrigerator while maintaining a lower temperature in the freezer compartment by utilizing two evaporators

Slim counter height dimensions

Ideal 24" footprint offers full 5.1 cu.ft. storage capacity in a slim fit

Cycle defrost

This system utilizes user-friendly automatic defrost operation in the fresh food section and efficient manual defrost operation in the freezer compartment

Adjustable glass shelves

Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple clean-up

Door storage

Store tall bottles and condiments right on the door for convenient access

Fruit and vegetable crisper

Get the longest life and best taste out of produce by storing it in a convenient slide drawer

Wine shelf

Removable scalloped wine shelf is included to store champagne and wine bottles

Hidden evaporator

Cold wall design with hidden evaporator creates a seamless, easy to clean interior

Interior light

Automatically illuminates when you open the door

Adjustable thermostat

Dial thermostat located inside for easy temperature management

Pro style handle

Stainless steel handle adds an attractive touch

Reversible door

User-reversible door swing for added flexibility

100% CFC free

Environmentally friendly design without ozone-damaging chemicals

CARB Compliant

Eco-friendly hydrocarbon-based refrigerant for a greener footprint that meets current CARB regulations

24" Wide European Refrigerator-Freezer

Includes a full refrigerator and freezer section for undercounter use

Peak24 Series

European-made collection for recessed installation featuring large capacity interiors, ENERGY STAR certified performances, and versatile style

ENERGY STAR certified

Rated by the DOE to perform with more efficiency than federal standards require, saving your unit energy and you on higher utility costs

Specifications

Warranty

Parts	1 Year
Labor	1 Year

Dimensions & Weight

Width	23.63 in.
Height	32.38 in.
Length	23 in.
Weight	100 lbs.

Cubic Feet Measurement & Dimensional Weight

Cubic Feet Measurement	10.18 ft³
Dimensional Weight	126.61 lbs.
Total of Cubes	10.18 ft³
Total of Dimensional Weight	126.61 lbs.

Overview Refrigerator-Freezer

Nominal Height	33.0" (84 cm)
Height of Cabinet	32.38" (82 cm)
Height to Hinge Cap	32.63" (83 cm)
Nominal Width	24.0" (61 cm)
Width	23.63" (60 cm)
Nominal Depth	23.0" (58 cm)
Depth	23.0" (58 cm)
Depth with Handle	24.63" (63 cm)
Depth with door at 90°	45.38" (115 cm)
Capacity	5.04 cu.ft. (143 L)
Defrost Type	Cycle
Door	Black
Cabinet	Black
US Electrical Safety	ETL
Canadian Electrical Safety	ETL-C
Energy Usage/Year	330.0kWh/year
Amps	1.2
Voltage/Frequency	115 V AC/60 Hz
Weight	100.0 lbs. (45 kg)
Parts & Labor Warranty	1 Year
Compressor Warranty	5 Years
UPC	761101067506
Door Swing	RHD
Reversible	Yes
Adjustable Shelves	Yes
Crisper Qty	1
Crisper Finish	Transparent
Crisper Cover	Glass
Wine Bottle Shelving	Yes
Interior Light	Yes
Refrigerator - Interior Height	18.0" (46 cm)
Refrigerator - Interior Width	21.0" (53 cm)
Refrigerator - Interior Depth	18.0" (46 cm)
Refrigerator - Capacity	4.5 cu.ft
Refrigerator - Shelf Type	Glass
Refrigerator - Shelf Qty	2
Refrigerator - Full Door Shelves	3
Refrigerator - Temperature Range	36°F to 46°F
Freezer - Interior Height	5.25" (13 cm)
Freezer - Interior Width	19.0" (48 cm)
Freezer - Interior Depth	11.5" (29 cm)
Freezer - Capacity	0.6 cu.ft
Thermostat Type	Dial
Refrigerant Type	R600a
Refrigerant Amount	0.92 oz.
High Side PSI	180.0
Low Side PSI	80.0
Level Legs	2
Compressor Step Height	5.5" (14 cm)
Compressor Step Width	21.0" (53 cm)
Compressor Step Depth	6.0" (15 cm)
Sound Level	32.6
